Years of manufacture: 1990 - 1992
Made in: Japan Kawasaki
Remote control: no
Power consumption: 400 W
Dimensions: 434 x 185 x 438 mm (WxHxD)
Weight: 17,5 kg
Connections Number of inputs: 7
o 1 Phono (Cinch + GND): MM 2.5 mV/47 kOhm, MC 200 µV/100 Ohm
o 1 Tuner (Cinch): 150 mV / 47 kOhm
o 1 AUX (Cinch): 150 mV / 47 kOhm
o 1 CD (Cinch): 150mV / 47 kOhm
o 1 CD balanced: 150 mV / 10 kOhm
o 2 Tape (Cinch): 150mV / 10 kOhm
Number of outputs:
o Speaker A
o Speaker B
o Pre Out
o Headphones
o 2x Rec out
Continuous power (at THD)
o 8 Ohm: 2 x 150W (DIN, 1 kHz, THD 0,005%)
o 4 Ohm: 2 x 250W (DIN, 1 kHz, THD 0.7%)
Dynamic power
o 4 Ohm: 2 x 350 W
o 2 Ohm: 2 x 500 W
Total harmonic distortion: 0.004% (3db at nominal output 150W, 8 ohms)
Frequency response: 1 - 250,000 Hz (+0, -3 dB, 1W).
Inputs:
o MM: 2.5mV-160mV / 47kOhm / 95dB SNR at 5mV.
o MC: 200uV-12mV / 100Ohm / 77dB SNR at 0.5mV
o balanced: 150mV / 10kOhm
o other: 150mV / 47kOhm (Source Direct: 10kOhm / 110dB SNR)
Output (level/impedance):
o A or B: min. 4 Ohm
o A + B: min. 8 Ohm
Tone control:
o Bass: 8 dB at 100 Hz.
o Treble: 8 dB at 10 kHz
Loudness: yes; +7dB at 100 Hz, +6dB at 10 kHz
Subsonic: yes; 16Hz, 12dB/oct
Mute: yes
Direct/Line-Straight: yes
